NOTE: For Impression Plus

Models only. Not

available on 1¼ " valve.

REPLACEMENT PARTS:

For Impression Plus

Models Only

PISTON ASSEMBLY

Item No. Part No. Description Qty.

CV3005 1” spacer stack assembly 1

CV3430 1.25” spacer stack assembly 1

2 CV3004 Drive cap assembly 1

3 CV3135 O-ring 228 1

CV3011 1” piston assembly downflow 1

CV3011-01 1” piston assembly upflow 1

CV3407 1.25” piston assembly downflow 1

5 CV3174 Regenerant piston 1

6 CV3180 O-ring 337 1

7 CV3105 O-ring 215 1

8 CV3556 Screw, 1/4-20x1-1/2 18-8SS 1

9 CCI-00318337 Nut, 1/4-20 HEX 18-8SS 1

10 CV3016 QC2 clamp assembly (includes screw & nut) 1

11 CV3452 O-ring 230 1

12 CV3015 WS1 QC2 Tank adapter assembly (includes O-rings) 1

CV3001-04 1” body assembly downflow 1

CV3001-04UP 1” body assembly upflow 1

CV3001 1” body assembly downflow 1

CV3001UP 1” body assembly upflow 1

CV3020 1.25” body assembly downflow 1

14 CV3541 Drive backplate 1
